Ultra-precision
Lightweight & compact size
Powerful detector
Distortion-free
Introducing the InfiRay Mate Mal38 Thermal Imaging Attachment - 384x288, 1948m. Encased in a magnesium alloy housing, the MAL38 is not only 50% lighter but also significantly more precise. This thermal attachment is designed for users seeking a compact, value-driven solution without compromising on performance. It supports practical functions such as removable buttons, a laser range finder (LRF), and a monocular extension, making it an ideal companion for any hunting expedition.
Meeting high-precision requirements, the MAL38 maintains a "POI1MOA" accuracy even when paired with high-calibre rifles. Weighing over 20% less than comparable products and more compact than previous models, the MAL38 delivers high-performance imaging with its 384x288 resolution detector and 12um pixel size. The optical system provides a distortion-free image, even when used with a 10x daytime scope, while the advanced algorithms enhance image quality by adjusting to different environments such as forests, plains, and cities.
The MAL38's design includes versatile, removable buttons that can be placed anywhere on the rifle for ease of use, even when the user's focus is on the target. The remote control, equipped with an ultra-low power consumption solution, attaches magnetically for automatic charging. Additionally, the Mate series includes a power bank accessory, extending the device's battery life by approximately seven hours. The optional LRF extension not only improves accuracy but also serves as a power bank, extending the MAL38's four-hour battery life.
InfiRay's MAL38 is engineered to function as a thermal imaging monocular when used with the IOM accessory, which can also serve as an independent optic scope. The MAL38's robust design, lightweight construction, and high-quality detection capabilities make it an invaluable tool for hunters. With a 1.03-inch, 1024x768 OLED display, IP67 waterproof rating, and compatibility with various accessories, the MAL38 offers ultra-precision, reliability, and user-friendly operation in diverse and challenging conditions.
Detector Parameters | ||
Resolution, Pixels | 384 x 288 | |
Pixel Size, Um | 12 | |
Netd, Mk | -/< 30 | |
Frame Rate, Hz | 50 | |
Optics Parameters | ||
Objective Lens, Mm | 38 | |
Field Of View (H X V), Degrees / M At 100 M | 7.0 x 5.3 / 12.3 x 9.2 | |
Recommended Magnification Of The Day Scope, X | G1/G2: 1 - 5 | |
G3/G4: 6 - 8 | ||
E-Zoom | Attachment mode: x1 | |
Monocular Mode: X1/X2/X4 | ||
Detection Range, M | (Target size: 1.7mx0.5m, P(n)99%) | 1948 |
Display Parameters | ||
Type | OLED | |
Resolution, Pixels | 1024 x 768 | |
Electrical Parameters | ||
Battery | Built-in battery + Infiray battery Pack | |
Max. Battery Life, H | 5 + 7.5 | |
Usb Interface | Type-C | |
Physic Parameters | ||
Body Material | Magnesium Alloy | |
Ip Rating | IP67 | |
Remote Control | Support | |
Built-In Memory, Gb | 32 | |
Aim Point, Moa | 1 | |
Weight, G | 500 | |
Dimension, Mm | 138 x 62 x 71 | |
Adapter Ring | M52x0.75 |
Free Shipping | No |
---|
