2600m detection range
12um 640x512 high capacity sensor
1.03 AMOLED display with 2560x2560 resolution
Introducing the InfiRay Tube TH50 V2 Thermal Imaging Riflescope - 640x512, 2600m. Standing out as a top-tier device, combining an exceptional sensor with powerful 50mm optics to achieve a remarkable detection range of up to 2600 meters. This advanced thermal scope features the industry-leading InfiRay 12m 640x512 sensor, which, along with an advanced image processing algorithm, delivers unparalleled image clarity and detail. Even in adverse weather conditions such as heavy fog and rain, the built-in Ultra-clear mode ensures clear and precise imaging.
A key highlight of the TH50 V2 is its high-resolution 2560x2560 1.03 AMOLED display. This display provides an outstanding viewing experience with excellent optical parameters, significantly reducing visual fatigue during prolonged observation sessions. The scope also supports smooth magnification without flicker or stutter, offering users a comfortable and seamless viewing experience. Additionally, the TH50 V2 enhances zeroing accuracy with each scale unit achieving precision down to 1.2cm at 100 meters, allowing for more precise and accurate targeting.
The TH50 V2 includes a built-in microphone for audio recording, ensuring that both video and sound can be captured during use. The device also supports distance measurement on the screen when the optional Laser Ranging Finder (LRF) is connected via Bluetooth, providing increased shooting accuracy. The traditional style housing allows for mounting with standard 30mm rings, combining advanced technology with a familiar design, making it an excellent upgrade for those accustomed to traditional day scopes.
Powered by a built-in 6600mAh battery supplemented by a replaceable, 18500 battery, the TH50 V2 offers a maximum operating time of 8.5 hours, ensuring extended use without the need for frequent recharges. The device also supports external power supply via a 5V Type C connection. Weighing less than 950g without the 18500 battery and measuring 365x85x75mm, the TH50 V2 is both robust and lightweight, making it easy to handle and mount.
Detector Specifications | ||
Type | Uncooled Vox | |
Resolution, Pixels | 640 x 512 | |
Pixel Size, M | 12 | |
Netd, Mk | -/< 25 | |
Frame Rate, Hz | 50 | |
Optical Specifications | ||
Objective Lens, Mm | 50 | |
Field Of View (Hxv) | 8.8 x 7.0 | |
Linear Field Of View (Hxv), M At 100M | 15.4x12.3 | |
Optical Magnification, X | 3.5 | |
Digital Zoom, X | 1 - 4 | |
Eye Relief, Mm | 50 | |
Exit Pupil Diameter, Mm | 6 | |
Diopter, D | -5 - +3.5 | |
Detection Range, M | (Target Size: 1.7mx0.5m, P(n)99%) | 2600 |
Display Specifications | ||
Type | AMOLED | |
Resolution | 2560 x 2560 (1.03) | |
Battery Power Supply | ||
Battery | Built-in battery / 6600mAh + replaceable 18500 battery / 3.7V | |
Max. Operating Time (22C), H | 8.5 | |
External Power Supply | 5V (Type C) | |
Functions | ||
Wi-Fi / App | Support (InfiRay outdoor) | |
Photo / Video Recorder | Support | |
Mic | Support | |
Bluetooth | Support | |
Operational Characteristics | ||
Memory Capacity gb | 32 | |
Ip Rating | IP67 | |
Operating Temperature, C | -20 - +50 | |
Max. Recoil Power On Rifled Weapon (Eo), Joules | 6000 | |
Compatible Mounts | Standard 30 mm rings | |
Weight (Without The 18500 Battery), G | < 950 | |
Dimension, Mm | 365 x 85 x 75 |
