KSTAR UBR10 Memopower Plus Online Series Rack Mount UPS - 1000VA
R3,929.00
SKU
KSUBR10
Digital control guarantees high reliability
True double-conversion
Rack-mounted and floor-standing tower can be convertible
Description
The KSTAR UBR10 Memopower Plus Online Series Rack Mount UPS - 1000VA is a small capacity UPS of KSTAR, the output factor is 0.9, and power range is from 1kVA to 3kVA.
Deployment is very flexible, tower and rack-mounted can be configured according to customer's requirement. When the UPS is on battery mode, it can shut down unnecessary load and extend the backup time of the critical load.
Features
- True double-conversion
- Rack-mounted and floor-standing tower can be convertible
- Patented mimic LCD of which content can be rotated according to the type of deployment
- Digital control guarantees high reliability
- Output receptacle control for non-critical load shedding capability
- Eco mode operation for energy saving
- Emergency power off function(epo)
- Generator compatible
- Communications:rs-232,USB,snmp card (optional), relay card (optional)
- Bypass can be used when UPS is off(setted in LCD)
- Cold start
Specifications
| Model | UBR10 |
| Capacity | 1000VA/900W |
| Input | |
| Nominal Voltage | 208/ 220/230/240Vac(L+N+PE) |
| Operating Voltage Range | 110 to 300Vac @(0 to 60%) Load120 to 300Vac @(60 to 70%)Load, 140 to 300Vac @(70 to 80%)Load;160 to 300Vac @(80 to 100%)Load |
| Operating Frequency Range | 50Hz: 45 to 55Hz, 60Hz: 55 to 65Hz Auto Sensing |
| Power Factor | > 0.85@25%Load>0.95 @50%Load>0.97@75%Load>0.99 @ Nominal voltage& 100%Load |
| Output | |
| Output Voltage | 208/220/240Vac:230Vac (Default) |
| Power Factor | 0.9 |
| Voltage Regulation | +/- 1% |
| Synchronized Range | 45-55Hz 0.02Hz@ 50Hz, 55-65Hz 0.02Hz@60Hz |
| Frequency Battery Mode and None Synchronized Range | (50/60+/-0.2)Hz |
| Crest Factor | 3:1 |
| Harmonic Distortion | ≤3% with linear load |
| (THDv) | ≤5% with non-linear load |
| Wave Form | Pure Sinewave |
| Transfer Time | Utility to Battery : 0ms Utility to Bypass: 4ms(Typical) |
| Efficiency | |
| AC Mode | 88% |
| Battery Mode | 84% |
| ECO Mode | 94% |
| Battery | |
| Battery Type | 12V/9Ah |
| Numbers | 2 |
| Maximum Charging Current | 1.0A |
| Charging Voltage (Vdc) | 27.4+/-1% |
| Protect | Over-Voltage(14.7v) / Low-Voltage(10v) |
| Protection Overload Capacity | |
| Line Mode | 105%-150%, 30s turn to bypass mode >150% 300ms turn to bypass mode |
| Battery Mode | 105%-150%, exceed 30s shutdown >150% exceed 300ms shutdown |
| Indicators | |
| LED and LCD Display | Load/Battery/Input/Output/Operating Mode Information |
| Alarm | |
| Battery Mode | Sounding every 4 seconds |
| Battery Low | Sounding every second |
| Overload | Sounding every 0.5 seconds |
| Fault | Continuously sounding |
| Management | |
| Smart RS-232/USB (Preferential) | External Modbus card supported by RS232,Software supports Windows Family,Linus,FreeBSD |
| Intelligent Slot | SNMP (Standard or mini) independent to RS-232(Optional) |
| Environment | |
| Operating Temperature | 0 degree Celsius to 40 degree Celsius |
| Humidity Range | 0 to 9% (Non-condensing) |
| Altitude | <1500m |
| Physical | |
| Dimension | 440mm x 430mm x 86.5mm (W x D x H) |
| Net Weight | 13.2kg |
| Standards | |
| Safety | IEC/EN62040-1 |
| EMC | IEC/EN62040-2 |
| Free Shipping | No |
|---|
