Meteo Control BlueLog DIN 24V DC Rail Power Supply
R1,529.00
SKU
4400300027
The Meteo Control Blue'Log DIN 24V DC Rail Power Supply can be particularly well fastened on a top-hat rail thanks to its design an can emit up to 4.2 Amps
Description
The Meteo Control Blue'Log DIN 24V DC Rail Power Supply can be particularly well fastened on a top-hat rail thanks to its design and can emit up to 4.2 Amps
Specifications
| DC voltage | 24 V |
| Nominal current | 4.2 A |
| Power range | 0 - 4.2 A |
| Nominal power | 100.8 W |
| Residual ripple | 150 mVp-p |
| Voltage settings range | 24 - 29 V |
| Current tolerance | +-1.0% |
| Linearity | +-1.0% |
| Load control | +-1.0% |
| Steepness | 2700 ms, 80 ms / 230 VAC |
| Holding time (typ.) | 50 ms / 230 VAC |
| Power range | 88 - 264 VAC / 124 - 370 VDC |
| Freq. range | 47 - 63 Hz |
| Energy efficiency | 89% |
| AC current | 3 A / 115 VAC |
| Overload protection | 105.84 - 136.08 W |
| Overvoltage protection | 30 - 35 V |
| Dimensions | 100 x 93 x 56 mm (WxHxD) |
| Weight | 350 g |
| Free Shipping | No |
|---|
