Victron Energy MultiPlus-II GX 24-3000/70-32 Inverter/Charger - 230V
R32,099.00
SKU
3800700192
Uninterrupted power supply
Display and Wi-Fi
Setting load limits
Parallel and three-phase operation
Shipping restrictions apply.
Manufacturer's Website
Description
The Victron Energy MultiPlus-II GX 24-3000/70-32 Inverter/Charger - 230V communicates with a solar charger, batteries, and other devices to control a grid-connected, off-grid, or remote power installation. Capable of parallel operation for increased power output, or battery charge-rates, the MultiPlus-II GX can also be configured for three-phase supply. A host of advanced features - such as uninterrupted power supply, setting load limits, and supplementing limited grid-power availability with battery power - can all be controlled straight from your phone or smart device. Remote monitoring is also possible.
Please Note: Picture used for illstrative purposes ONLY.
Features
- Uninterrupted power supply
- Display and Wi-Fi
- Setting load limits
- Parallel and three-phase operation
- Supplementing limited grid-power availability with battery power
Specifications
| Power control & Power assist | Yes |
| Transfer Switch | 32 A |
| Maximum Ac Input Current | 32 A |
| Auxiliary Output Yes | (32 A) |
| Inverter | |
| DC Input Voltage Range | 19 - 33 V |
| Output Voltage | 230 VAC - 2 % |
| Frequency | 50 Hz - 0,1 % (1) |
| Cont. Output Power At 25 C (3) | 3000 VA |
| Cont. Output Power At 25 C | 2400 W |
| Cont. Output Power At 40 C | 2200 W |
| Cont. Output Power At 65 C | 1700 W |
| Maximum Apparent Feed-In Power | 3000 VA |
| Peak Power | 5500 W |
| Maximum Efficiency | 94 |
| Zero Load Power | 13 W |
| Zero Load Power In Aes Mode | 9 W |
| Zero Load Power In Search Mode | 3 W |
| Charger | |
| Ac Input Voltage Range | 187-265 VAC |
| Input Frequency | 45 - 65 Hz |
| Charge Voltage 'Absorption' | 28,8 V |
| Charge Voltage 'Float' | 27,6 V |
| Storage Mode | 26,4 V |
| Maximum Battery Charge Current (4) | 70 A |
| Battery Temperature Sensor | Yes |
| General | |
| Interfaces | BMS-Can, USB, Ethernet, VE.Direct, Wi-Fi |
| External Ac Current Sensor (Optional) | 50 A 100 A |
| Programmable Relay (5) | Yes |
| Protection (2) | a g |
| Ve.Bus Communication Port | For parallel and three-phase operation, remote monitoring and system integration |
| General Purpose Com. Port | Yes, 2x |
| Remote On-Off | Yes |
| Operating Temperature Range | -40 to +65 C (fan assisted cooling) |
| Humidity (Non-Condensing) | max 95 % |
| Enclosure | |
| Material & Colour | Steel, blue RAL 5012 |
| Protection Category | IP22 |
| Battery-Connection | M8 bolts |
| 230 V Ac-Connection | Screw terminals 13 mm (6 AWG) |
| Weight | 20 kg |
| Dimensions (Hxwxd) Mm | 506 x 275 x 147 |
| Free Shipping | No |
|---|
