Victron SmartSolar Charging Controller - MPPT 75/10

R2,009.00

SKU

5001000015

Bluetooth Smart built-in: dongle not needed Ultra-fast Maximum Power Point Tracking (MPPT) Battery Life: intelligent battery management Programmable battery charge algorithm Day/night timing and light dimming option Programming, real-time data and history display options

Safe & Secure Shopping

Satisfaction Guaranteed

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Please Note: Victron products are, according to the Victron supplier of South Africa, only to be supplied to installers with professional Victron training. Unfortunately we are prohibited from selling Victron products to customers who do not meet these requirements. For further information please contact Victron at: [email protected]

Manufacturer's Website

Description

The Victron SmartSolar Charge Controller is intelligent, featuring a wireless solution to set-up, monitor and update the controller using Apple and Android smartphones, tablets or other devices. A solar charger gathers energy from your solar panels, and stores it in your batteries. Using the latest, fastest technology, SmartSolar maximises this energy-harvest, driving it intelligently to achieve full charge in the shortest possible time. SmartSolar maintains battery health, extending its life.

Features

Bluetooth Smart built-in: dongle not needed
VE.Direct
Ultra-fast Maximum Power Point Tracking (MPPT)
Load output
Battery Life: intelligent battery management
Programmable battery charge algorithm
Day/night timing and light dimming option
Programming, real-time data and history display options

Specifications

Brand	Victron Energy
Battery voltage	12 / 24 Auto Select V
Rated charge current	10 A
Nominal PV power	12 V:145 W / 24 V:290 W
Max PV short circuit current	13 A
Automatic load disconnect	Yes
Maximum PV open circuit voltage	75 V
Peak Efficiency	98%
Self-consumption	12 V: 25 mA 24 V: 15 mA
Charge voltage 'absorption'	14,4V / 28,8V (adjustable)
Charge voltage 'float'	13,8V / 27,6V (adjustable)
Charge algorithm	multi-stage adaptive (eight pre-programmed algorithms)
Temperature compensation	-16 mV / -32 mV / °C
Protection	Battery reverse polarity (fuse) / Output short circuit / Over temperature
Operating Temperature	-30 to +60 °C (full rated output up to 40°C)
Humidity	95 %, non-condensing
Data Communication port	VE.Direct
Enclosure
Colour	Blue (RAL 5012)
Power terminals	6 mm^2 / AWG10
Protection category	IP43 (electronic components), IP22 (connection area)
Weight	0.5 kg
Dimensions	100 x 113 x 40 mm
Saftey	EN/IEC 62109-1, UL 1741, CSA C22.2
